This articulated-arm bridge saw is configured for stone fabrication workshops processing artificial granite, porcelain tiles, and natural stone slabs. The 360-degree rotating arm provides flexible access to large workpieces without repositioning the material.
Parameter Category | Specification |
|---|---|
Model | YL-LA-1200 |
Cutting Disc Diameter | 350mm |
Maximum Cutting Length | 3200mm |
Maximum Cutting Thickness | 120mm |
Cutting Table Size | 3200 × 1600mm |
Parameter Category | Specification |
|---|---|
Main Motor Power | 15kW |
Electrical Supply | 380V, 50/60Hz, 3-phase |
Drive System | AC servo with gear reduction |
Spindle Speed | 0-3000rpm |
Cutting Feed Speed | 0-6m/min |
Parameter Category | Specification |
|---|---|
Lifting Arm Vertical Stroke | 400mm |
Arm Horizontal Rotation | 360° |
Positioning Accuracy | ±0.2mm |
Cutting Straightness | ±0.15mm/m |
Machine Weight | 5000kg |
The 360-degree rotating arm covers the entire 3200 × 1600mm table surface, allowing operators to make cross cuts, rip cuts, and angle cuts from a single machine position. The arm extends 1800mm from the pivot point, enabling processing of slabs positioned outside the table boundary for oversized materials.
The vertical lifting stroke of 400mm accommodates material thicknesses from 5mm wall tiles up to 120mm granite blocks. The motorized height adjustment includes a digital readout for precise depth control when performing partial cuts or groove operations.
The single-pivot arm design requires approximately 30% less floor space than comparable bridge saws with gantry structures. The open-front table configuration allows loading of slabs using forklifts or overhead cranes from three sides, improving material handling efficiency in production layouts.
The machine is engineered specifically for hard stone and porcelain materials commonly used in commercial construction and renovation projects.
The 350mm diameter diamond blade is specified for cutting artificial granite (quartz agglomerate), porcelain tiles, sintered stone, marble, and natural granite. The spindle accepts blades with 50mm arbor holes, matching industry-standard tooling available from multiple abrasive suppliers.
The guided rail system maintains cutting straightness within ±0.15mm per meter of cut length, suitable for seam joints in countertop installation requiring tight fits. Miter cuts up to 45 degrees are supported for laminated edge profiles and outside corner joints.
The cutting head includes a water distribution system that delivers 8-12L/min of cooling water to the blade contact point, suppressing dust and cooling the diamond segment during cutting. The table surface includes integrated water channels that direct slurry to a central drain for collection and filtration.
This model is designed for daily production use in small to medium stone processing facilities serving residential and commercial construction projects.
For standard 20mm artificial granite slabs, the machine achieves feed rates of 2-4m/min, completing a standard 3-meter countertop cut in approximately 1-1.5 minutes. Production capacity averages 40-60 square meters of finished material per 8-hour shift, depending on cut complexity.
Blade changes require approximately 10 minutes using standard tools. Angle adjustments for miter cuts use a calibrated degree scale with positive stops at 0 degrees and 45 degrees, reducing setup time between standard operations.
The lifting arm configuration allows a single operator to complete loading, cutting, and unloading operations for standard slab sizes. The manual traverse controls provide direct feedback during cutting, reducing the learning period for new operators compared to fully automated CNC systems.
The machine is manufactured under ISO 9001 quality management systems and carries CE marking according to machinery directive requirements. Electrical components meet EN 60204-1 standards for industrial equipment.
The machine includes a 12-month warranty covering manufacturing defects in the frame, motor, gearbox, and drive components. The warranty includes free replacement of covered parts that fail under normal operating conditions.
Delivery includes on-site installation by a technician for commercial orders within standard service regions, along with 2 days of operator training covering machine operation, basic maintenance, and blade replacement procedures.
The machine cuts materials from 5mm thin porcelain tiles up to 120mm thick granite blocks, covering standard applications for wall tiles, floor tiles, countertops, and structural stone elements.
Yes, the cutting head tilts to 45 degrees for miter cuts used in laminated countertop edges and outside corner joints. Positive stops at 0 and 45 degrees simplify setup for standard operations.
The machine requires 380V, 50/60Hz, three-phase electrical supply with a 40A dedicated circuit. A water supply connection with 0.2-0.4MPa pressure is also required for blade cooling.
Standard delivery includes one set of service tools, one spare diamond blade, water pump components, and electrical fuses for initial operation. Additional consumable parts are available through spare parts channels.
