Yuanli 5-axis CNC water jet cutting machine adopts cold cutting technology with no thermal effect, integrated with a 5-axis linkage system to realize 45-degree bevel cutting in one process. This multifunctional equipment caters to complex shaping and bevel processing demands for stone, metal, glass and other materials, suitable for diverse industrial applications. Equipped with an AC servo control system and 37kW power unit, it delivers stable processing performance for commercial production.
Equipped with a 5-axis AC servo system, this equipment can complete 45-degree bevel cutting in a single pass, without secondary trimming or grinding. For stone processing, it supports seamless countertop joint processing and edge bevel processing, improving the fitting accuracy of splicing. For metal fabrication, it can directly cut bevels for welding preparation, reducing subsequent processing procedures and improving production efficiency.
The equipment adapts to a wide range of materials and processing scenarios. For the stone and bathroom industry, it supports large slab cutting, seamless basin and hot bending basin processing, quartz and sintered stone 45° bevel cutting, kitchen countertop processing, sink and faucet hole cutting, marble and granite slab cutting, decorative marble inlay cutting, complex stone pattern cutting, and large-format sintered stone fabrication. For metal processing, it covers mild steel thick plate cutting, stainless steel precision cutting, aluminum sheet and plate cutting, copper and brass cutting, titanium and alloy material processing, precision metal component fabrication, complex contour cutting, industrial equipment component processing, structural steel fabrication, mechanical engineering part cutting, and aerospace and automotive component cutting. It also works for glass, ceramic and carbon fiber composite material processing.
voltage | 380V | core components | PLC, Engine, Motor, Pump |
machinery test report | Provided | warranty | 1 Year |
video outgoing-inspection | Provided | key selling points | Multifunctional |
rated power | 37kw(49.62hp) | place of origin | China |
weight (kg) | 4250 | brand name | yuanli |
Product name | Water Jet cutting machine | Voltage | 220V/380V/415V |
CNC control system | AC servo system | cutting accuracy | ±0.1mm |
repeatability | ±0.01mm | Fast positioning accuracy | ±0.025mm |
Power | 50/60HZ | Warranty of core components | 1 Year |
Applicable Industries | Machinery Repair Shops | Showroom Location | Germany |
The equipment adopts an AC servo CNC control system, with fast positioning accuracy of ±0.025mm, cutting accuracy of ±0.1mm and repeatability of ±0.01mm. The system supports complex contour and curved shape cutting, and can process customized patterns according to design files, adapting to flexible and diversified production demands.
As a cold cutting method, the Water Jet process generates no heat affected zone and no thermal deformation during processing. The cutting edge has minimal burrs and a smooth surface, which can reduce subsequent polishing and secondary processing. The equipment structure is designed for long-term heavy-duty processing, adapting to continuous operation in industrial production lines.
The equipment provides a 1-year warranty for the whole machine and core components. Before delivery, a machinery test report and video outgoing-inspection are provided to verify equipment performance. The brand has a showroom in Germany for on-site equipment inspection, and supports overseas after-sales service to solve equipment problems in time. The product complies with ISO and CE production standards.
The 5-axis system can realize 45-degree bevel cutting and three-dimensional complex shape processing in one pass, reducing secondary processing procedures and improving production efficiency. It can achieve higher fitting accuracy for splicing and welding preparation processes.
This equipment is suitable for stone processing, kitchen and bathroom fabrication, metal manufacturing, glass processing, ceramic production, and composite material processing industries, supporting various cutting and shaping processes.
Yes, each machine undergoes strict inspection before delivery, with a formal test report and inspection video provided to clients for confirmation.
