This 2026 model CNC Water Jet cutting machine operates with a rated working pressure of 420Mpa, paired with a 37kw high-pressure pump to support fast cutting of thick materials across multiple material types. The system is designed for general industrial cutting operations, reducing the need for multiple dedicated cutting machines for facilities that process metal, stone, and glass materials. The cold cutting process eliminates thermal deformation on cut parts, which preserves material properties for metals and prevents cracking in brittle materials such as stone and glass.
The machine uses a 3-axis CNC platform with AC servo control, which delivers consistent positioning accuracy for repeated batch cutting tasks. The system supports programmed cutting paths for complex 2D shapes, suitable for high-volume production environments with stable output requirements. The 380V industrial power configuration supports long-hour continuous operation for commercial production schedules.
Original factory specifications are listed as follows:
voltage | 380V | core components | PLC, Motor, Pump |
warranty | 1 Year | rated power | 37kw(49.62hp) |
place of origin | China | weight (kg) | 3000 |
brand name | yuanli | After-sales Service Provided | Engineers available to service machinery overseas |
Product name | Water Jet cutting machine | Warranty | 12 Months |
Voltage | 220V/380V/415V | CNC control system | AC servo system |
cutting accuracy | ±0.1mm | repeatability | ±0.01mm |
Fast positioning accuracy | ±0.025mm | Power | 50/60HZ |
Certification | iso ce | - | - |
The 420Mpa pressure system supports cutting of mild steel, stainless steel, aluminum, copper, and titanium alloys, with no heat-affected zone that would alter material properties. It is suitable for cutting structural steel parts, mechanical components, and metal fabrication blanks, with smooth cut edges that reduce secondary grinding work.
For stone processing, the machine cuts marble, granite, and sintered stone slabs for countertops, decorative inlays, and tile patterns. It also processes ceramic plates, porcelain slabs, and flat glass components, supporting custom shape cutting for building material and decoration applications.
The machine is configured for fast setup and operation, with a user-friendly CNC control interface that reduces training time for production staff. For enterprise users with overseas facilities, the manufacturer provides on-site engineer support for installation, troubleshooting, and operational guidance. The equipment is delivered as a single unit with export-standard packaging to withstand international shipping conditions.
This machine supports cutting of metals (mild steel, stainless steel, aluminum, copper, titanium alloys), stone (marble, granite, sintered stone), glass, ceramic plates, and composite materials, covering most common industrial cutting materials.
The machine operates at a rated working pressure of 420Mpa, which supports efficient cutting of thick materials while maintaining consistent cut quality across different material types.
Yes, the manufacturer provides overseas engineer service for installation, commissioning, and operational training for international buyers, with 12 months of warranty coverage for core components.
